BB5055HIL

5055 Tractor Specs

5055 Engine

MODEL  A2300T3-UTR_4
FUEL SYSTEM  WATER-COOLED DIESEL
DISPLACEMENT, IN  139.5
NUMBER OF CYLINDERS  4
FUEL TANK SIZE, GAL  11.8
RATED ENGINE POWER, HP  55
RATED SPEED, RPM  2600
MAX PTO POWER, HP  44
DPF / SCR / DOC - DPF / DOC

5055 Transmission

TYPE  5055S/CS - SYNCHRO | 5055H/CH - HST
NUMBER OF GEARS  5055S/CS - 16F / 16R | 5055H/CH - 4 RANGE

5055 Hydraulics

MAXIMUM TOTAL FLOW, GPM  5055S/CS - 16.4 | 5055H/CH - 15.7
IMPLEMENT PUMP CAP, GPM  5055S/CS - 11.4 | 5055H/CH - 10.7
STEERING PUMP CAP, GPM  5
3P CATEGORY  1
HITCH LIFT CAPACITY, LB  3,306
AT 24 INCHES BEHIND LINK ENDS, LB  2,425

5055 Dimensions

OVERALL LENGTH, IN, 3P  127.4
OVERALL WIDTH, IN  64.9
HEIGHT TO TOP OF ROPS, IN  5055S/H - 98.4 | 5055CS/CH - 97
WHEELBASE, IN  71.1
MIN. GROUND CLEARANCE, IN  15.5
WEIGHT, LB  5055S/H - 3,836 | 5055CS/CH - 4,349

5055 PTO

540, 540E - 584, 791

5055 Loader - Model BBL500

Standard Bucket Size (in.)  72
Maximum Lift Height (in.)  106.6
Dig Depth (in.)  3.1
Lift Capacity To Full Height At Pivot Pin (lbs.)  2,700
Breakout Force (lbs.)  3,660
Shipping Weight (lbs.)  1,075

Optional -5055 Backhoe - Model BBH500

Standard Bucket Size (in.)  16
Maximum Dig Depth (in.)  91.2
Shipping Weight (lbs.)  1,500
